机油冷却器产品概要

①	Braking ability	3	0.3 Kw
		5	0.5 Kw
		10	0.75 Kw
		20	1.5 Kw
		30	2.2 Kw
		50	3.75 Kw
②	Sign	5	Type change
③	Temperature regulation	Nothing	Room-steep type
③	Temperature regulation	K	Temperature fixed type
④	Species	Nothing	Basic type bell-cooling machine
		T	Ubber type
		C	Cutting fluid

强制冷却方式1.
采用3-sang冷却机,效率High sex.
2.系统自动调节温度
易于调节温度.
3.机油冷却配制专用泵机内部
实现Low噪音.
4.多样化型号
选择面广泛.
5.精巧Use of 设计
便于安装和.

1. Large size / small size automatic control kneading machine bed
2. Industrial oil pressure machine
3. Applicable Uses Various kinds of use of hydraulic oil system (Plastic machine, discharge processing machine, oil pressure oak bed, etc.)
4. Stool and automation equipment.

Oil cooler, cooling system, hydraulic oil, lubricating oil, etc. Indoor temperature,
change of temperature, control of temperature,

1. Limitations on freezing temperature and oil temperature using this product.
(* Refer to the standard usage range under the reference.)
2. Standard temperature range Lower temperature deviation - - 10 ℃ ~ + 10 ℃
※ . ) ℃ 20 ℃ at room temperature ℃ 10 ℃ 30 ℃范围之间.
3. Applicable electrical capacity of the ceiling of the main power supply. (Reference description)

- 1 kcal / h: 1 kg during a short period of time Water conversion
1 ° C Time demand heat quantity unit
- BTU / h: 1 unit in a short time 1Lb water conversion 1 ℉
Time demand heat quantity unit

1Kcal	: 3.986 BTU
1BUT	: 0.252 Kcal
1RT	: 3320 Kcal / h
1Kw	: 860 Kcal / h
1Hp	: 632 Kcal / h

(Kcal / h)
- Cp = oil specific heat Kcal / Kg ° C (ISO VG # 32 → 0.47)
- r = specific weight Kg / ㎣ (876)
- Q = CP × r × Vs × Δt - Q = Vs = amount of oil (㎣ / h)
- Δt = temperature ° C. (Inlet-Outlet)
